Authentication and security
|
● Wi-Fi Protected Access - with WPA2 or WPA3, including WPA2-Entperprise authentication
● 802.1X, RADIUS Authentication, Authorization, and Accounting (AAA)
● Segmentation via VLANs (up to 16)
● 802.11r and 802.11i
● Guest network can also authenticate against a Social Login account: Google and Facebook
|
|
Maximum clients
|
● Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point, or 1000 in a system
|
|
Maximum # of Access Points
|
● 50
● Recommended up to 25
|
|
Max # of Mesh Extenders
|
● Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops
|
|
Management Compatibility
|
● A group of access points and mesh extenders comprised of only CBW150AX and CBW151AXM devices may be managed as a single entity.
● CBW150AX access points must not be installed on the same management network and CBW140AC or CBW240AC access points.
● CBW150AX and CBW151AXM devices are supported by Cisco Business Dashboard versions 2.4.1 and higher.
|
|
802.11ax
|
● 2x2 downlink MU-MIMO with two spatial streams
● Uplink/downlink OFDMA
● TWT
● BSS coloring
● MRC
● 802.11ax beamforming
● 20-, 40-, 80- channels
● PHY data rates up to 1.488 Gbps (80 MHz with 5 GHz and 20 MHz with 2.4 GHz)
● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
● 802.11 DFS
● CSD support
● WPA3 support
|
|
802.11ac
|
● 2x2 single-user/multi-user MIMO with two spatial streams, up to 867 Mbps in 5GHz
● 20-, 40-, and 80-MHz channels
● Dynamic Frequency Selection (DFS)
|
|
Ethernet ports
|
● Authentication with 802.1X or MAC filtered
● Dynamic VLAN or per port
● Traffic locally switched or tunneled back to Master AP
|
|
Data rates supported
|
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
|
|
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
|
|
802.11n data rates on 2.4 GHz: 6.5 to 300 Mbps (MCS0-MCS15, HT 20/40)
|
|
802.11ac data rates on 5 GHz: 6.5 to 867 Mbps (MCS0-MCS9)
|
|
802.11ax data rates on 2.4 & 5GHz: 6.5 to 1200 Mbps (MCS0-MCS11)
|
|
Integrated antenna
|
2.4GHz: peak gain 4dBi, internal antenna, omnidirectional in azimuth
5GHz: peak gain 5dBi, internal antenna, omnidirectional in azimuth
|
|
Maximum number of
non-overlapping channels
|
A (A regulatory domain):
● 2.412 to 2.462 GHz; 11 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.700 GHz; 8 channels
◦ excludes 5.600 to 5.640 GHz
● 5.745 to 5.825 GHz; 5 channels
B (B regulatory domain):
● 2.412 to 2.462 GHz; 11 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.720 GHz; 12 channels
● 5.745 to 5.825 GHz; 5 channels
D (D regulatory domain):
● 2.412 to 2.462 GHz; 11 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.720 GHz; 12 channels
● 5.745 to 5.865 GHz; 7 channels
E (E regulatory domain):
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.700 GHz; 8 channels
F (F regulatory domain)
● 2.412 - 2.472 GHz; 13 channels
● 5.180 - 5.320 GHz; 8 channels
● 5.745 to 5.805 GHz; 4 channels
H (H regulatory domain):
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.745 to 5.825 GHz; 5 channels
I (I regulatory domain):
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
|
K (K regulatory domain)
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.620 GHz; 7 channels
● 5.745 to 5.825 GHz; 5 channels
Q (Q regulatory domain):
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.700 GHz; 11 channels
R (R regulatory domain):
● 2.412 to 2.472 GHz; 13 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.660 to 5.700 GHz; 3 channels
● 5.745 to 5.805 GHz; 4 channels
S (S regulatory domain)
● 2.412 - 2.472 GHz; 13 channels
● 5.180 - 5.320 GHz; 8 channels
● 5.500 -5.700 GHz; 11 channels
● 5.745- 5.825 GHz; 5 channels
T (T regulatory domain):
● 2.412 to 2.462 GHz; 11 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.720 GHz; 12 channels
● 5.745 to 5.825 GHz; 5 channels
Z (Z regulatory domain):
● 2.412 to 2.462 GHz; 11 channels
● 5.180 to 5.320 GHz; 8 channels
● 5.500 to 5.700 GHz; 8 channels
◦ excludes 5.600 to 5.640 GHz
● 5.745 to 5.825 GHz; 5 channels
|
|
Note: This varies by regulatory domain. Refer to the product documentation for specific details for each regulatory domain.
|
|
Available transmit power settings
|
2.4 GHz
Up to 20 dBm
|
5 GHz
Up to 20 dBm
|
|
Note: The maximum power setting will vary by channel and according to individual country regulations.
Refer to the product documentation for specific details.
|
|
Interfaces
|
● 1x Gigabit Ethernet (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
|
|
Indicators
|
● Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
|
|
Dimensions (W x L x H)
|
● Access point (without mounting bracket): 5.92 x 5.92 x 1.57 in. (150.4 x 150.4 x 39.9 mm)
|
|
Weight
|
● Access point without mounting bracket or any other accessories: 11.6 oz (330 g)
|
|
Environmental
|
Operating
● Temperature: 32° to 104°F (0° to 40°C)
● Humidity: 0% to 95% (noncondensing)
● Maximum altitude: 9843 ft (3000 m) at 40°C
Nonoperating (storage and transportation)
● Temperature: –22° to 158°F (-30° to 70°C)
● Humidity: 0% to 95% (noncondensing)
● Maximum altitude: 15,000 ft (4570 m) at 25°C
|
|
System
|
● 1 GB DRAM, 512MB flash
● 1GHz quad core processor
|
|
Powering options
|
● Use the Cisco Business passive PoE injector (included with select country-specific models)
or
● 802.3af/at Ethernet switch; a Cisco Business Switch with PoE is recommended (CBS220/250/350 series); or Cisco Business PoE injector (CB-PWRINJ-XX)
|
|
Power draw
|
● 9.2W (maximum, on PoE)
|
|
Mounting and physical security
|
Included with the access point:
● Mounting bracket and hardware
|
|
Warranty
|
Cisco Business 3-year limited hardware warranty
Free software updates, no service contract required
|
|
Compliance
|
● Safety:
◦ UL 60950-1
◦ CAN/CSA-C22.2 No. 60950-1
◦ IEC 60950-1
◦ EN 60950-1
◦ IEC 62368-1
◦ EN 62368-1
◦ UL/CUL 62368-1
● Radio approvals:
◦ FCC Part 15.247, 15.407
◦ RSS-247
◦ EN 300328, EN 301893
◦ EN 50385
◦ ARIB-STD 66
◦ ARIB-STD T71
● EMC
◦ EMI and susceptibility (Class B)
◦ FCC Part 15B
◦ ICES-003
◦ VCCI(Japan)
◦ EN 301489-1 and -17
◦ EN 55032, EN55035
● IEEE standards:
◦ IEEE 802.3
◦ IEEE 802.3ab
◦ IEEE 802.3af/at
◦ IEEE 802.11a/b/g/n/ac/ax
◦ IEEE 802.11h, 802.11d
● Security:
◦ 802.11i, WPA2, WAP3, WPA
◦ 802.1X
◦ AES
● Extensible Authentication Protocol (EAP) types:
◦ EAP-Transport Layer Security (TLS)
◦ EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
◦ Protected EAP (PEAP) v0 or EAP-MSCHAPv2
◦ EAP-Flexible Authentication via Secure Tunneling (FAST)
◦ PEAP v1 or EAP-Generic Token Card (GTC)
◦ EAP-Subscriber Identity Module (SIM)
● Multimedia:
◦ Wi-Fi Multimedia (WMM)
● Other:
◦ FCC Bulletin OET-65C
◦ RSS-102
|
